Description
Wichard Self-Locking Tack Shackles:
- Self-locking twisted shackle with allen head pin forged in grade 316L stainless steel.
- The pin is locked into one of the indentations.
- The head of the pin does not stick out from the shackle body and thus eliminates any risk of snagging.
- No risks of loose due to vibrations.
- Outstanding working and breaking loads.
- Specific model for tack point.
- Designed for adjustment to the width of the gooseneck.
Applications:
- Tack point.
Working load (WL): for nautical applications.
Working Load Limit (WLL): for industrial applications only.
The safety factor is 5 times the breaking load.
WLL = Breaking load / 5
| Self Locking Tack Shackles | 1233 | 1234 |
|---|---|---|
| Materials | 316 stainless steel grade | 316 stainless steel grade |
| Working Load (kg) | 520 | 800 |
| Breaking load (kg) | 1500 | 2300 |
| Weight (g) | 48 | 110 |
| A (mm) | 45 | 59 |
| B (mm) | 16 | 21 |
| C (mm) | 6 | 8 |
| D (mm) | 13 | 17 |
| D diameter (mm) | 6 | 8 |
| E (mm) | 4 | 6 |
| F (mm) | 60 | 79 |
| G (mm) | 33 | 45 |
